Energy Saving 18000 BPH Pet Bottle Water Filling Machine
Decrease The Overall Production Cost Blowing Filling Capping Combine
The integrated blowing filling capping system is a new generation of beverage production line developed by our company. It integrates the functions of PET bottle blow molding machine, liquid filling machine, and bottle capping machine. This beverage machinery effectively saves the production process such as intermediate material transfer, empty bottle treatment, storage, etc.
Technical Information:
| Weight: | 20,000 kg |
| After-sales service provided: | online support, video technical support, free spare parts, on-site installation, commissioning and training, on-site maintenance and repair services |
| Warranty: | 1 year |
| Main selling point: | high productivity |
| Main engine power: | 5.5+7.5kW |
| Productivity: | 18,000 bottles/hour (500 ml) |
| Filling materials: | beer, milk, water, oil, juice |
| Applicable bottle: | diameter: Φ60-Φ90, height: 180-260 |
| Filling volume: | 200ML—1500ML |
| Marketing type: | general product |
product properties:
| Mechanical test report: | if |
| Video inspection: | if |
| Core component warranty: | 1 year |
| Core components: | motor, pump, PLC, engine |
| Filling material: | flowing liquid |
| Usage: | beverage filling and packaging |
| Function: | Energy-saving automatic filling machine |
| Applicable to: | water filling line |
| Control: | PLC+touch screen |
| Material: | stainless steel 304/316 |
| Features: | high efficiency |
| Filling nozzle: | 2/4/6 (customized) |
Note:
1. The production capacity is based on bottles of 500ml. The actual capacity may be affected by the size and shape of customers' bottles.
2. Best Crown reserves the right to change these data according to the specific conditions.
Technical features:
1. The six-valve blowing valve group, three blowing and two recycling energy-saving solutions, enable customers to save energy by more than 45%.
2. Customer-customized full servo stretching system to meet various stretch ratios.
3. Complete and fully automatic CIP system to ensure the sanitary requirements of the inner surface of the equipment.
4. Positive pressure 100-level filling environment in the filling area.
5. Adopt PROFIBUS intelligent control technology to realize whole line control and intelligent data report, each Real-time monitoring of links.
6. Non-contact imported electronic flowmeter filling system and mechanical valve fixed liquid level filling valve to ensure accuracy.
7. Imported ion dust removal system to ensure the safety of packaging.
